• Model NO.：PFT002
• Brand Name：Perfect
• Surface Finish：Bright Finish
• Raw Material：Stainless Steel, Carbon Steel
• Trademark：Perfect
• Origin：Jiangsu China
• HS Code：8207400000
• Production Capacity：1000 PCS,Per Day

Procuct Name131Pcs Thread Repair Set for Repairing Broken Thread in Metal BoxMaterialInstallation Handle/ Tang Breaker: Carbon Steel      Drill Bit/ Thread Tap/ Insert: HSSSize

5Pcs Drill Bit: 5.3mm, 6.3mm, 8.3mm, 10.4mm, 12.4mm

5Pcs Tap: M5x0.8, M6x1.0, M8x1.25, M10x1.5, M12x1.75

5Pcs Installation Tool & Break Pin: No.8, No.9, No.11, No.13, No.15

1Pc Hex Key

110Pcs Thread Insert: M5 x 0.8 x 6.7mm, M6 x 1.0 x 8.0mm, M8 x 1.25 x 10.8mm,

                                      M10 x 1.5 x 13.5mm, M12 x 1.75 x 16.3mm

Surface FinishBright FinishPackage131 Pieces in One Metal BoxFeatures1. This guarantees easy installation and allows for full load use of tapped hole, ensuring protection against stress and vibration.
2. Synchronized-Thread Insert is thin walled due to synchronized internal external threads.
3. Thin cross sectional area allows for installation in areas of limited space and clearance material.
4. Synchronized-Thread Insert Having a flange on the top of the insert will insure that the insert will have positive placement and cannot wind down into the newly repaired hole.
5. On installation the bottom internal threads of the insert are cold rolled to expand the mating external threads into the base material locking the insert in place.
