• Model NO.：AL251
• Structure：Box Joint
• Handle Color：Red and Black
• Application Age：Adult
• Use Place：Inflammable and Explosive Area
• Size：Common
• Feature：Non Sparking
• Certificate：Bam,FM,GS
• Transport Package：Plastic Bag,Box,Carton,Pallet
• Specification：6", 10", 12", 14"
• Trademark：WEDO
• Origin：China
• HS Code：8203200000
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. AL251 Structure Box Joint Handle Color Red and Black Application Age Adult Use Place Inflammable and Explosive Area Size Common Feature Non Sparking Certificate Bam/FM/GS Transport Package Plastic Bag/Box/Carton/Pallet Specification 6", 10", 12", 14" Trademark WEDO Origin China HS Code 8203200000 Production Capacity 50000PCS/Year

Product Description

ITEM CODE	SIZE
AL251-1002	6"
AL251-1004	10"
AL251-1006	12"
AL251-1008	14"

Above item no. is only for Aluminium Bronze material, Besides Aluminium Bronze, WEDO also supply in Beryllium Copper, below are differences of two material.

Aluminum Bronze Non-sparking Tools
1. Appropriate for operation with ethylene concentration below 7.8%
2. Surface Color: Silver Yellow
3. Micro-magnetic
4. Hardness: 20-30 HRC
5. Tensile Strength: 782N/mm²-989N/mm²
6. Elasticity Limit: 450N/mm²-550N/mm²
7. Extensibility: δ≥5%

Beryllium Copper Non-sparking Tools
1. Appropriate for operation with hydrogen concentration below 21%,
2. Surface Color:Golden Yellow
3. Non-magnetic
4. Hardness: 30-40 HRC
5. Tensile Strength: 1117N/mm²-1326N/mm²
6. Elasticity Limit: 840N/mm²-880N/mm²
7. Extensibility: δ≤1.0%

To ensure the explosion-proof performance, after the raw materials are melt with scientific ratio, QC personnel will take sample piece to do drop weight and friction test according to GB/T 10686-2013 standard. The test is conducted under the highest level ExIIC,  hydrogen concentration 21%. Only if the samples are tested qualified can the next step of production be carried out.

The explosion-proof performance of WEDO non-sparking tools is guaranteed for lifetime.
