• Model NO.：DIN382 Hexagon Die Nut
• Place of Origin：Jiangsu, China (Mainland)
• Brand Name：Perfect
• Type：Hexgaon Dies
• Raw Material：Alloy Steel,High Speed Steel
• Surface Treatment：Tin,Ticn,Tialn
• Unit Packing：Plastic Box
• Transport Package：Plastic Box +Inner Box+Carton
• Specification：According to Requirement
• Trademark：Perfect
• Origin：Jiangsu China
• HS Code：8207400000
• Production Capacity：1000 PCS,Per Day

Product NameThreading DieMaterialAlloy Steel, HSS(4241,4341,M2,M35)TypeHexagon Dies,Round Dies, Open Mouth Dies, Adjustable Die;Machine Die,Hand DieStandardDIN(Metric Size/UNC/UNF/BSW/BSF),GOST 9740, ANSI standard. HardnessAlloy steel: HRC56-57, HSS4241: HRC59-61, HSS4341: HRC63-64, HSS 6542: 64-65Thread typeLeft hand,right handCoatingTIN,TICN,TIAINMeasuringMetric and InchApplicationFor making outer threads; Adjustment screw allows die to be set for different classes of fit.
Can be used to cut new threads or clean up existing threadsBusiness TypeManufacturer
Sizes:
SizeOutsideItem No.M3×0.519×5mmFT1304030050M3.5×0.619×5mmFT1304035060M4×0.719×5mmFT1304040070M4.5×0.7519×7mmFT1304045075M5×0.819×7mmFT1304050080M6×119×7mmFT1304060100M7×122×9mmFT1304070100M8×1.2522×9mmFT1304080125M9×1.2522×9mmFT1304090125M10×1.527×11mmFT1304100150M11×1.527×11mmFT1304110150M12×1.7536×14mmFT1304120175M14×236×14mmFT1304140200M16×241×18mmFT1304160200M18×2.541×18mmFT1304180250M20×2.541×18mmFT1304200250M22×2.550×22mmFT1304220250M24×350×22mmFT1304240300M27×360×25mmFT1304270300M30×3.560×25mmFT1304300350M33×3.560×25mmFT1304330350M36×460×25mmFT1304360400M39×470×30mmFT1304390400M42×4.570×30mmFT1304420450M45×4.585×36mmFT1304450450M48×585×36mmFT1304480500M52×585×36mmFT1304520500M3×0.3519×5mmFT1304030035M4×0.519×5mmFT1304040050M5×0.519×5mmFT1304050050M6×0.7519×5mmFT1304060075M7×0.7522×9mmFT1304070075M8×0.7522×9mmFT1304080075M8×122×9mmFT1304080100M9×122×9mmFT1304090100M10×127×11mmFT1304100100M11×127×11mmFT1304110100M12×136×10mmFT1304120100M12×1.2536×10mmFT1304120125M12×1.536×10mmFT1304120150M14×136×10mmFT1304140100M14×1.2536×10mmFT1304140125M14×1.536×10mmFT1304140150M16×1.541×14mmFT1304160150M18×1.541×14mmFT1304180150M18×241×14mmFT1304180200M20×1.541×14mmFT1304200150M20×241×14mmFT1304200200M22×1.550×16mmFT1304220150M22×250×16mmFT1304220200M24×1.550×16mmFT1304240150M24×250×16mmFT1304240200M26×1.560×18mmFT1304260150M27×1.560×18mmFT1304270150M27×260×18mmFT1304270200M28×1.560×18mmFT1304280150M30×1.560×18mmFT1304300150M30×260×18mmFT1304300200M32×1.560×18mmFT1304320150M33×1.560×18mmFT1304330150M33×260×18mmFT1304330200M35×1.560×18mmFT1304350150M36×1.560×18mmFT1304360150M36×260×18mmFT1304360200M36×360×25mmFT1304360300M38×1.570×20mmFT1304380150M39×1.570×20mmFT1304390150M39×270×20mmFT1304390200M39×370×20mmFT1304390300M40×1.570×20mmFT1304400150M40×270×20mmFT1304400200M42×1.570×20mmFT1304420150M42×270×20mmFT1304420200M42×370×30mmFT1304420300M45×1.585×22mmFT1304450150M45×285×22mmFT1304450200M45×385×36mmFT1304450300M48×1.585×22mmFT1304480150M48×285×22mmFT1304480200M48×385×36mmFT1304480300M50×1.585×22mmFT1304500150M52×1.585×22mmFT1304520150M52×285×22mmFT1304520200M53×385×36mmFT1304530300


SizeOutsideItem No.1/8-4019×5FT13040000013/16-2419×7FT13040000021/4-2019×7FT13040000035/16-1822×9FT13040000043/8-1627×11FT13040000057/16-1427×11FT13040000061/2-1236×14FT13040000079/16-1236×14FT13040000085/8-1141×18FT13040000093/4-1041×18FT13040000107/8-950×22FT13040000111"-850×22FT13040000121-1/8-760×25FT13040000131-1/4-760×25FT13040000141-3/8-660×25FT13040000151-1/2-670×30FT13040000161-5/8-570×30FT13040000171-3/4/585×36FT13040000181-7/8-4-1/285×36FT13040000192"-4-1/285×36FT1304000020





SizeOutsideItem No.G1/8-2827×11FT1304000021G1/4-1936×10FT1304000022G3/8-1941×14FT1304000023G1/2-1441×14FT1304000024G5/8-1450×16FT1304000025G3/4-1450×16FT1304000026G7/8-1460×18FT1304000027G1"-1160×18FT1304000028G1-1/8-1170×20FT1304000029G1-1/4-1170×20FT1304000030G1-3/8-1185×22FT1304000031G1-1/2-1185×22FT1304000032G1-3/4-11100×22FT1304000033G2"-11100×22FT1304000034
