• Model NO.：MG50379
• Specification：200mm
• Trademark：MAGMA
• Origin：China
• HS Code：82073000
• Production Capacity：10, 000 Sets , Year

Basic Info.

Model NO. MG50379 Specification 200mm Trademark MAGMA Origin China HS Code 82073000 Production Capacity 10, 000 Sets / Year

Product Description

Diesel Engine Timing Tool Set - Ford TDCi / PSA HDi / Mazda 1.4, 1.6

Used to lock and hold the camshaft, crankshaft, flywheel in the timed position.
Applications:
Ford: Fiesta/Fusion 1.4 (02-08), Focus/Fusion 1.6 (04-08), Focus/C-Max 1.6 (03-07), Engines: 1.4 / 1.6 TDCi
Ford: Mondeo 2.0 / 2.2 TDCi (04-07), Transit 2.0 TDCi, 2.0 TDI, 2.4 TDI (00-08)
Citroën: C1 (05-10), C2 (03-10), C3 (02-10), C4/C5 (04-08), Xsara (02-06), Xsara Picasso (04-10), Berlingo (05-11), Engines: 1.4 / 1.6 HDi
Peugeot: 107/1007 (05-10), 206 (01-12), 207 (06-12), 307 (01-08), 407 (04-11), Engines: 1.4 / 1.6 HDi
Mazda: 2 (02-10), 3 (04-12), Engines: 1.4 / 1.6 D
OEM#: 21-234/303-675, 21-262/303-734/0194C, 21-263/303-735/0194B, 21-260/303-732/0194A.



------------------------------------------------------------------------------------------

Timing
When an automotive timing belt is replaced, care must be taken to ensure that the valve and piston movements are correctly synchronized. Failure to synchronize correctly can lead to problems with valve timing, and this in turn, in extremes, can cause collision between valves and pistons in interference engines. This is not a problem unique to timing belts since the same issue exists with all other cam/crank timing methods such as gears or chains. To help alleviate a timing belt from being incorrectly installed, the timing belt has painted marks on the surface of the belt that line up with markings on the camshaft gears and crankshaft gear so that the belt is perfectly aligned and properly positioned.
.
