• Model NO.：ESL180,50,30,60,35
• Transport Package：Seaworthy Packing
• Specification：CE
• Trademark：SUNNY
• Origin：China
• Production Capacity：100 Sets Per Month

Basic Info.

Model NO. ESL180/50/30/60/35 Transport Package Seaworthy Packing Specification CE Trademark SUNNY Origin China Production Capacity 100 Sets Per Month

Product Description

ESL180/50 Sack/Bags Vacuum Lifter/Tube Lifter
ESL180/50 Sack Vacuum LifterMain components:

Vacuum blower: Siemens vacuum blower, model GS4.0, power supply 380V, 4.0KW, maximum vacuum flow 170cbm/h, maximum vacuum pressure -55kpa



Lifting tube: diameter 180mm, tube length 2550mm, maximum lifting height 1700mm, maximum loading 70kg for semi-porous, 80kg for dense.
SUS304 suction pad special for sack, the dimension was 230*380mm,with sponge rubber rings



A ball bearing integrated upper rotation jointer with single way valve to prevent the goods falling down in case of power lost.
Two-hands control unit with a rotation handle for up and down, the brake handle for release, the handle were extended for higher stack
A plastic vacuum filter mounted on the column.
A vacuum regulator mounted on the vacuum blower which protect the blower in case overheat, the preset vacuum pressure is -45kpa
8M vacuum feeding pipe of Diameter 52mm for vacuum connection
A vacuum filter standard for keep air clean
The lifter was designed for transportation or handling the materials at:
Max.carrying capacity: 80kg for dense, 70kg for semi-porous

Guarantee & Aftersales service:

1)Guarantee the complete machine for 18 months, except the consumable parts.
2) 24hour technical support by email or calling.
3) User-friendly English manual for machine using and maintaining.
